Syringe & Syringe Module Negative Pressure Pump 3 Part Differential Hematology Analyzer

Syringe & Syringe Module Negative Pressure Pump 3 Part Differential Hematology Analyzer
Syringe & Syringe Module Negative Pressure Pump 3 Part Differential Hematology Analyzer

Large Image :  Syringe & Syringe Module Negative Pressure Pump 3 Part Differential Hematology Analyzer

Product Details:
Place of Origin: Shenzhen
Brand Name: Hicorpwell
Certification: CCC & CE
Model Number: HCW-PPD 128
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Packaging Details: overall dimension (mm):124*12*12 mm
Delivery Time: 10-15working days
Payment Terms: T/T, L/C
Supply Ability: 100 sets Per Week

Syringe & Syringe Module Negative Pressure Pump 3 Part Differential Hematology Analyzer

Description
Displacement: 2ml Stroke(mm): 25.5
Life Cycle: 1 Million Accuracy Of Suction And Drainage: 1.0%
Repeatability Of Suction And Drainage: 0.5% Working PreSsure: 0.2Mpa
Chamber Material: Stainless Steel Overall Dimension (mm): 124*12*12
High Light:

Syringe Module Negative Pressure Pump

,

Hematology Analyzer Suction Pump Assembly

Syringe & Syringe module Negative Pressure Pump 3-Part Differential Hematology Analyzer



Product characteristics:



This suction pump assembly is dedicated to 3-Part differential hematology analyzer, long travel, high accuracy, long life and maintenance-free. The specifications of the three-channel plunger are different, taking into account the suction and drainage for micro volumetric sample, diluent and hemolytic agent . Cavity is moulded, low cost, good consistency.



Application:



It is mainly used in 3-Part differential hematology analyzer, in which the empty travel interval of sampling pump body can effectively avoid the sampling abnormal movement caused by linkage, improve sampling accuracy and reduce control complexity.



Name Sample acquisition pump Hemolytic agent pump Diluent pump
Displacement (ul) 50 1130 8050
Trip (mm) 25.0 40.0 40.0
Stepper motor step angle(°) 1.8
Motor current (A) 2.0
Screw pitch (mm) 2.50
Linear distance per step of motor (mm) 0.0125
Fluid volume per step of motor (ul/step) 0.02513 0.35343 2.51327
Accuracy of suction and drainage Note 1%
Repeatability of suction and drainage (Cv) Note 0.5%
Working pressure 0.3MPa
Life cycle 1 million
Working medium Clear water, oil, weak acid and base, etc.
Thread Interface Form Barbed type
overall dimension (mm) 193*70*83.7



Remark:



Note 1: The nominal accuracy of suction and drainage is measured at a range of no less than 10% displacement.



Note 2: The nominal repetition accuracy is measured at a range of no less than 10% displacement.
