Commercial ODVA Fiber Optic Patch Cables Mini SC LC MPO IP67 Mechanical Resistance

Commercial ODVA Fiber Optic Patch Cables Mini SC LC MPO IP67 Mechanical Resistance

Commercial ODVA Fiber Optic Patch Cables Mini SC LC MPO IP67 Mechanical Resistance

Product Details:

Place of Origin: China
Certification: IEC 60794-2-10/11
Model Number: ODVA LC Duplex CPRI Cable Waterproof Fiber Optic Patch Cables RRU(RRH)

Payment & Shipping Terms:

Minimum Order Quantity: 10sets
Price: negotiation
Packaging Details: Max 100m/ per reel for 5.0 mm OD cable
Payment Terms: Western Union, L/C, T/T
Supply Ability: 5000pcs Per Week
Contact Now
Detailed Product Description
Cable Type: ODVA LC Duplex CPRI Cable Fiber Optic Patch Cables RRU(RRH) Connectors: Customized Or LC Connectors
Paintcoat Color: Black Cable Purpose: Aerospace, Airborne, Marine, Ground Vehicle,tactical And Even Automotive Commercial Applications
Length: Per Reel.100m -1000m Application: Outdoor Communication
High Light:

sm fiber optic cable


fiber patch cables

Outdoor ODVA mini SC/LC/MPO IP67 Waterproof connector Fiber Optic Patch Cables



ODVA harsh environment cable assemblies are installation-friendly for fixed or mobile applications


and transmit reliably data over long distances under severe environmental conditions.

Key Features

1• Robust fiber-optic connector for 12 channels with screwed mating mechanism

2• IP67 protection, salt-mist proof, and EMI protection

3• High shock, vibration, and mechanical resistance

4• Broad temperature range and wide range of indoor and outdoor cables

5• Easy, reliable and cost-effective installation


Optical performance

1. Insertion loss / IEC 61300-3-34

2. singlemode typ. ≤ 0.2 dB 97% ≤ 0.45 dB

3. multimode typ. ≤ 0.2 dB 97% ≤ 0.50 d

Return loss / IEC 61300-3-6 singlemode ≥ 50 dB



Product Parameters




End A

Multichannel Hermaphroditic Beam Fiber Optic Connector

End B

LC,or SC,FC,ST......

Cable Diameter(mm)

4.0mm/ 7.0mm/ 8.0mm

Material of jacket


Fiber Core

4,8,12 or specified




Operating Wavelength(nm)







Insertion Loss(Max.dB)



Return Loss(Min.dB)



Mechanical Features


≤1000N(main cable)


≤100N(Branch cables)



Mating time

500 Min





Operating Temperature(℃)


Storage Temperature(℃)





























Application :


Fiber-to-the-Antenna (FTTA)

Latest and next-generation mobile communication systems(GSM, UMTS, CMDA2000, TD-SCDMA, WiMAX, LTE,etc.) deploy fiber-optic feeders to link the base station with the remote unit at the antenna mast.

Automation and industrial cabling

ODVA provides highest reliability and operating safety. The ruggedized design provides highest mechanical and thermal robustness which keeps the data lines alive even in case of
shock, strongest vibration, or accidental misuse.

Surveillance systems

Security camera manufacturers chooseODVA connectors for its compact size and robust design. ODVA assemblies are easy to install even in areas difficult to access and provide highest installation safety.

Naval and ship building

The high corrosion resistance convinced both naval and civil ship builders to use ODVA assemblies for on-board communication systems. The nickel plated connectors withstand humid and salty environments and guarantee life times of 20 years and beyond.


offers a range of mobile cabling systems and ODVA assemblies for temporary cable installations
required for the broadcasting of sport events, car racing, etc.and for temporary connections in case of natural hazards.


                      Commercial ODVA Fiber Optic Patch Cables Mini SC LC MPO IP67 Mechanical Resistance 0
