Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord with LSZH Jacket

China Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord with LSZH Jacket supplier

Large Image :  Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord with LSZH Jacket

Product Details:

Place of Origin: China
Brand Name: HICORPWELL
Certification: IEC 60794-2-10/11
Model Number: Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord

Payment & Shipping Terms:

Minimum Order Quantity: 10sets
Price: negotiation
Packaging Details: 200 pcs per carton
Payment Terms: Western Union, L/C, T/T
Supply Ability: 5000pcs Per Week
Contact Now
Detailed Product Description
Cable Type: Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord Connectors: Customized Or LC UPC Connectors
Color: Blue Cable Purpose: Aerospace, Airborne, Marine, Ground
Length: 1M , 3M,5M,10M,100M Application: Outdoor Communication

Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord with LSZH Jacket





Patch Cords are used to provide optical connection for fiber optic electronics. The use of the patch cord



provides a quick and easy method for routing fiber patches in data centers, head-ends, cellular hubs



and central offices.





*Single mode and Multimode



*Cable 0.9mm,2.0mm,2.4mm or 3.0mm with simplex or duplex and 4,6,8,12,24,48 cores



*Custom order length



*Cable color green , yellow , orange and customized



*All parts compliant with RoHS



*IEC standard compatible



*GR-326-CORE Compliant





Products info





type

PC

SPC

UPC

APC

Insertion Loss

SM

≤0.20dB

≤0.20dB

≤0.20dB

≤0.25dB

MM

≤0.30dB

≤0.30dB

≤0.30dB

≤0.30dB

Return Loss

SM

≥50dB

≥50dB

≥50dB

≥60dB

MM

≥40dB

≥40dB

≥40dB

≥40dB

Mating Durability(500 timer)

Additional Loss≤0.1dB, Return Loss Variability<5dB

Temperature Stability(-40°C~85°C)

Additional Loss≤0.2dB, Return Loss Variability<5dB

Operating Temperature

-40°C~+85°C

































Order Information



CODE

CONNECTOR

CABLE SIZE

FIBER TYPE

CABLE TYPE

BOOT



SM Simplex

0.9mm

9/125

Yellow PVC

Blue



MM Simplex

2.0mm

OM3

Orange PVC

Beige



APC Simplex

3.0mm

50/125

White PVC

Green



SM Duplex



62.5/125

Yellow LSZH

Black



MM Duplex





Orange LSZH

Blue and Yellow



APC Duplex





White LSZH

Red and Black





LC























Patch cord is a fiber optic cable used to attach one device to another for signal routing.





LC stands for Lucent Connector. It is a small form-factor fiber optic connector, half the size of the SC.


UPC stands for Ultra Physical Contact.The end faces are given an extended polishing for a better surface finish. These connectors are often used in digital, CATV, and telephony systems.

APC stands for Angled Physical Contact The end faces are still curved, but they’re angled at an industry-standard eight degrees. This maintains a tight connection. These connectors are preferred for CATV and analogue systems.





How to Choose The Right Fiber Optic Cable Type?



PS:The difference of OM4 and OM3 fiber mode as the following


1. OM4 was developed specifically for VSCEL laser transmission and allows 10 Gig / second link distances



of up to 550 Meters (compared to 300M with OM3).


2. The effective modal bandwidth for OM4 is more than double that of OM3.


3. For OM4 patch cable it is 4700 MHz.km while for OM3 it is 2000 MHz.km.



Duplex LC OM4 FTTH Multimode Fiber Optic Patchcord with LSZH Jacket
