| Parameter | Unit | LC/SC/ST/FC |
|---|---|---|
| SM(9/125) | MM(50/125 or 62.5/125) | |
| Insertion Loss | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 |
| Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥35 |
| Exchangeability | dB | ≤0.2 |
| Repeatability | dB | ≤0.2 |
| Durability | Time | >1000 |
| Operating Temperature | °C | -40~75 |
| Storage Temperature | °C | -45~85 |
| Parameter | Specification |
|---|---|
| Connector End A | Fiber Optic Connector |
| Connector End B | LC, SC, FC, ST, or specified |
| Cable Diameter | 4.0mm/7.0mm/8.0mm |
| Material of jacket | TPU |
| Fiber Core | 4, 8, 12 or specified |
| Mode | Singlemode | Multimode |
| Operating Wavelength | 1310/1550 | 850/1310 |
| Polishment | UPC | APC | UPC |
| Insertion Loss (Max.dB) | 1.5 | 1.0 |
| Return Loss (Min.dB) | 50 | 35 |
| Mechanical Features | Plug ≤1000N (main cable) Socket ≤100N (Branch cables) |
| Grade | IP68 |
| Mating time | 500 Min |
| Durability (Max.dB) | 0.2 |
| Repeatability (Max.dB) | 0.5 |
| Operating Temperature | -40~+85°C |
| Storage Temperature | -40~+85°C |
