Specifications
BNC to BNC SDI Cable
1.Best price
2.OEM are welcomed
Specifications:
Competitive price
In order to provide an one-stop service, we proudly offer cable assemblies for our customers.
we have own fully trained technicians to make it happen.
Each cable is fully tested for pin-pin continuity, as well as having a high voltage test to ensure
that there are no potential breakdown problems.
Every cable is fully inspected to ensure that it meets the requirements specified.
We do it according to customers' requirements.If you would like to discuss your requirements
or receive a quotation, please feel free to contact us.
We can make all types of cables as per customers' request.
|
MOCO P / N
|
cable assembly
|
|
Temp (min)
|
-40 deg
|
|
Temp (max)
|
200 deg C
|
|
Humidity (max)
|
<=95% [at 60 deg C / 140 F]
|
|
Vibration
|
15 g [10 Hz - 2000 Hz]
|
|
Shock Resistance
|
100 g [ 6 ms]
|
|
Salt Spray Corrosion
|
>144 hr
|
|
Shielding (min)
|
75 dB (10 MHz)
|
| Characteristic impedance | 50Ω 75Ω | Operating Temperature | -45~+65°C |
| Frequency Range | DC~4GHz(50Ω) | Dielectric Resistance | ≥5Ω |
| DC~2GHz(75Ω) | |||
| Dielectric Withstanding voltage | ≥1500V RMS | Disengage force | ≥0.6N |
| Contact resistance | Center conductor | ≤1.5mΩ | |
| Outer conductor | ≤1mΩ | ||
| Durability | Mating cycles | ≥500 | |
| Weatherproof Rate | IP67 | ||
| Material And Plating | Parts Name | Material | Plating |
| Body | Brass | nickel plated | |
| Male center contacts | Brass | gold plated | |
| Insulators | PTFE | — | |
| Gaskets | Beryllium copper | gold or nickel plated | |
| Crimp ferrules | Copper alloy | gold or nickel plated | |
| Suitable Cable Family | RG59 Cable | ||
