Transmission Visible Light Optimized BGOU Silica Fibers
10M-50M -100M
MOQ
negotiation
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HICORPWELL
Certification: IEC 60794-2-10/11
Model Number: Visible light optimized silica fibers (BGOU)
High Light:

Silica Bare Optical Fiber

,

BGOU Bare Optical Fiber

Payment & Shipping Terms
Packaging Details: Standard length: 10km per reel (as per your requirements)
Payment Terms: Western Union, L/C, T/T
Supply Ability: 1000KM Per Month
Specifications
Features: High Cost Effective;
Fiber Type: Visible Light Optimized Silica Fibers (BGOU)
Application: Mainly Applied In Visible To Infraredwaveband Transmission
NA Range:: 0.22±0.02(0.1to 0.28 On Request)
CCDR: CCDR:1:1.04,1:1.1,1:1.2 (1:1.06,1:1.15,1:1.25,1:1.4on Request)
Temperature Range[℃: 2
Coating MaTemperature Range[℃: 2
Specialty Fibers: (BGOU) Visible Light Optimized Silica Fibers
Product Description
Visible light optimized silica fibers (BGOU)

Features:

◆ High cost effective;


◆ Mainly applied in Visible to Infraredwaveband transmission;


◆ NA=0.22±0.02(0.1to 0.28 on request);


◆ CCDR:1:1.04,1:1.1,1:1.2 (1:1.06,1:1.15,1:1.25,1:1.4on request).





core[μm](±2%) 100 200 300 400 500 600 800 1000
cladding[μm](±2%) 110 220 330 440 550 660 880 1100
Coating material: Acrylate, Temperature range[℃]: -40-85
coating[μm](±3%) 245 400 450 550 770 840 1100 1300
coating material : Polymide, Temperature range[℃]: -65-300
coating[μm](±3%) 125 245 360 480 575 710 - -







Transmission Visible Light Optimized BGOU Silica Fibers 0Transmission Visible Light Optimized BGOU Silica Fibers 1
