HCW 34/530/650FA10 Large Core 200um 400um 600um 800um silica multimode Specialty Fiber

10M
MOQ
HCW 34/530/650FA10 Large Core 200um 400um 600um 800um silica multimode Specialty Fiber
Features Gallery Product Description Request A Quote
Features
Specifications
Fiber Range: HCW 200um 400um 600um 800um
Packing Size: 28*20*8cm
Coating Diameter: 1650um+-15um
Core Absorption @1530nm (dB/m): 1500um+-15um
Cladding Diameter: 2200um+-8um
Inner Cladding (N.A): >=0.22
Basic Infomation
Place of Origin: Guangdong China
Brand Name: Hicorpwell
Certification: CE & Rohs
Model Number: HCW200um 400um 600um 800um
Payment & Shipping Terms
Packaging Details: 45*40*38
Delivery Time: 12
Payment Terms: TT/Westunion
Supply Ability: 5000KM per Month
Product Description
Fiber Type
HCW 34/530/650FA10
HCW 34/530/650FA10
operating wavelength
1015-1115
1015-1600
core numerical aperture (i.e. diameter of a fiber)
0.10±0.01
0.10±0.01
core attenuation(dB/km@1200nm)
≤15
≤15
Numerical aperture of the first cladding
0.22±0.02
0.22±0.02
First cladding pump absorption(dB/M@915)
1.00±0.15
-
First cladding pump absorption(dB/M@976)
4.30
-
Numerical aperture of the second cladding
≥0.46
≥0.46
Second cladding pump absorption(dBM@915)
0.75
-
core diameter (of a fiber)(um)
34.0±2.5
34.0±2.5
First cladding diameter(um)
460.0±15.0(边-边)
460.0±10.0
Second cladding diameter(um)
530.0±10.0
530.0±10.0
Coating layer diameter(um)
650.0±15.0
650.0±15.0
Core package concentricity(um)
≤3.0
≤3.0
screening intensity(kpsi)
100
100

Characteristics of special optical fiber:



Enhanced nonlinear effect: By adjusting the refractive index distribution and geometric structure of the optical fiber, the nonlinear effect of the optical fiber can be enhanced, giving it unique advantages in the fields of fiber lasers, fiber sensing, etc.

High power tolerance: Special optical fiber uses high-purity materials and special cladding structure, can withstand high-power lasers, and is widely used in laser cutting, welding and other fields.



Specific band response: By doping with different rare earth elements, the optical fiber can have a higher absorption or emission efficiency for light in a specific band, and is used for fiber amplifiers, fiber lasers, etc. Special environmental adaptability: Special optical fiber can withstand harsh environments such as high temperature, high pressure, and radiation, and is suitable for aerospace, oil exploration and other fields. Sensing function: Special optical fiber can respond to physical quantities such as temperature, pressure, and strain, and is used to build optical fiber sensors for remote monitoring and control.


Application of special optical fiber:
Communication field: Wavelength division multiplexing system:
Special optical fiber can realize wavelength division multiplexing and increase the capacity of the communication system. Long-distance transmission: Low-loss special optical fiber is used for long-distance submarine communication systems.
Sensing field: Temperature sensing: used to monitor high temperature environments, such as fire alarms and industrial process control. Pressure sensing: used to measure the pressure of liquids or gases, such as oil pipeline monitoring.
Strain sensing: used to monitor the strain of structures, such as bridges and tunnels.
Laser field: Fiber laser: used for material processing, medical equipment, etc. Fiber amplifier: used for signal amplification in optical communication systems. Biomedical field: Endoscope: used for medical diagnosis and surgery.
Optical coherence tomography: used for medical imaging such as ophthalmology and dermatology. Defense and military field: Fiber optic gyroscope: used for inertial navigation systems. Fiber optic hydrophone: used for underwater target detection


Applications:

Some of the major areas where this type of fiber is commonly used include:

1. Materials processing: * Laser cutting, welding, and marking of metals, plastics, and other materials
* Additive manufacturing (3D printing) using laser-based techniques
* Micro-machining and precision drilling
2. Telecommunications: * High-power fiber amplifiers
for long-haul optical fiber communication systems
* Raman amplification in optical fiber networks
3. Scientific and industrial research: * Pump sources for solid-state lasers and nonlinear frequency conversion
* Laser-based spectroscopy and remote sensing applications
* Seed sources for high-energy pulsed lasers

The 30/250μm fiber geometry, combined with Ytterbium doping and the double-clad design, enables the generation


Packing and Shipping:

We use reliable and trusted shipping services to ensure that your Bare Optical Fiber is delivered to you on time and in perfect condition.

The standard shipping method for Bare Optical Fiber is through air freight. This allows for a faster and more efficient delivery process. For international orders, we use air freight services with tracking capabilities to ensure that your package can be traced at any point during its journey.  For domestic orders, we offer both standard and expedited shipping options. You can select your preferred shipping method during the checkout process. Once your order has been shipped, you will receive a confirmation email with your tracking number and estimated delivery date.



We take great care in packaging and shipping your Bare Optical Fiber, but in the rare case that your product arrives damaged, please contact us immediately for assistance.

Thank you again for choosing Bare Optical Fiber. We hope you enjoy the product!



FAQ:

  • Q: What is the brand name of this product? A: The brand name of this product is Hicorpwell.
  • Q: What is the model number of this product? A: The model number of this product is HCW-20FB.
  • Q: Where is this product made? A: This product is made in Guangdong, China.
  • Q: What certifications does this product have? A: This product is certified with CE and Rohs.
  • Q: What is the minimum order quantity for this product? A: The minimum order quantity for this product is 2.
  • Q: How is this product packaged? A: This product is packaged with dimensions of 45*40*38.
  • Q: What is the delivery time for this product? A: The delivery time for this product is 12 days.
  • Q: What are the payment terms for this product? A: The payment terms for this product are TT (Telegraphic Transfer) or Westunion.
  • Q: What is the supply ability for this product? A: The supply ability for this product is 5000KM per month.
