Typical Applications :
Diode Pumping Systems,Free Space Optics,Medical Sensing and Imaging,Other Industrial Applications,
Power Transmission from Visible Through Near-IR,Printing,Raman Pumping,SM and MM Communications,
Use as Input Fiber in a Power Combine.Other fiber diameters are available upon request.
Specifications & Performances
| Item | Description |
| Numerical Aperture | 105/125/250um |
| Attenuation @850nm | <12dB/km |
| Numerical ApertureNA | 0.22+/-0.02 |
| Core Dia | 105+/-3.0um |
| Cladding Dia | 125+/-2.0um |
| Coating Diameter | 250+/-15um |
| Core/Clad Offset | <3.0um |
| Coating Concentricity | >80% |
| Clad Non-Circularity | <2.0% |
| Coating Material | Dual UV Acrylate |
| Working Temperature | -40℃to+85℃ |
| Short-Term Bend Radius | >5mm |
| Long-term Bend Radius >9mm | |
| Proof Test Level | 200kpsi |
