rugged environmental adaptability, creating a solution tailored for mission-critical and harsh-environment applications.
**Application Scenarios**:
| Description | CAT8 | Part Number: | SMT-3011T8C6A-FTP |
| Size | rj45 | Golaplated: | 6 µ |
| Material | Polycabnate + Zinc Alloy | MOQ: | 1000 Pieces |
| Packing: | 1 Pieces/PE bag, 500 pieces/Carton | Packing Size | 53*32*23cm |
Specification
| Frequency | Return Loss Min | Attenuation Max |
NEXT Min |
PSNEXT Min |
ELFEXT Min |
PSELFEXT Min |
| (MHz) | (dB) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) |
| 1 | 20 | 1.84 | 74.3 | 72.3 | 68 | 65 |
| 4 | 23.01 | 3.69 | 65.27 | 63.27 | 55.96 | 52.96 |
| 10 | 25 | 5.89 | 59.3 | 57.3 | 48 | 45 |
| 16 | 25 | 7.51 | 56.24 | 54.24 | 43.92 | 40.92 |
| 20 | 25 | 8.43 | 54.78 | 52.78 | 41.98 | 39.98 |
| 31.25 | 23.64 | 10.64 | 51.88 | 49.88 | 38.1 | 35.1 |
| 62.5 | 21.54 | 15.36 | 47.36 | 45.36 | 32.08 | 29.08 |
| 100 | 20.11 | 19.78 | 44.3 | 42.3 | 28 | 25 |
| 200 | 18 | 28.97 | 39.78 | 37.78 | 21.98 | 18.98 |
| 250 | 17.32 | 32.84 | 38.33 | 36.33 | 20.04 |
17.04 |
| Cat5e UTP FTP SFTP Cable | ||||
| Conductor material | CCA,BC Copper | |||
| Conductor diameter | Solid one: 0.4mm, 0.45mm, 0.5mm | |||
| Stranded one: 24 AWG, 26 AWG, 28 AWG | ||||
| Num of Conductor | 2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P ,,,,, | |||
| Insulation material | PE , HDPE | |||
| Insulation diameter | 0.9±0.02mm | |||
| Jacket material | PVC, ROHS PVC, LSZH PVC | |||
| Cat6 /cat6a/cat7 UTP FTP SFTP Cable | ||||
| Conductor material | CCA,BC Copper | |||
| Conductor diameter | Solid one: 0.5mm, 0.56mm, 0.57mm | |||
| Stranded one: 23AWG, 24 AWG | ||||
| Num of Conductor |
2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P ,,,,,
|
|||
| Insulation material | PE , HDPE | |||
| Insulation diameter | 0.9±0.02mm | |||
| Jacket material | PVC, ROHS PVC, LSZH PVC | |||
