Product Description
FTTH drop cable with easy accessibility to the fiber and simple installation, FTTH cable can be directly connected to the homes.
It is suitable for connecting with communication equipment, and used as access building cable in premises distribution system.
The optical fibers are positioned in the center. Two parallel Fiber Reinforce Plastic (FRP) strength members are placed at the two sides.
Then, the cable is completed with LSZH sheath.
Cable Characteristics
Cable Technical Parameters
| Model | FTTH drop cable | |
| Fiber Count | 1-24 Cores | |
| Outer diameter (mm) | (2.0±0.2)×(5.0±0.3) | |
| Nominal weight(kg/km) | 21.7 | |
| Max.tensile Strength(N) | Short-term | 400 |
| Long-term | 200 | |
| Min.Bending Radius(mm) | Dynamic | 15D |
| Static | 7.5D | |
| Max.Crush Resistance(N/100mm) | Short-term | 2200 |
| Long-term | 1000 | |
| Jacket | LSZH | |
| Color | Cable | Black |
| Fiber | Blue | |
| Strength Members | 2×0.5mm FRP | |
| Environmental Protection | RoHS COMPLIANT | |
| Temperature range | Storage or transportation | -20~70℃ |
| Operation | -20~70℃ | |
| Installation | 0 ~ 50℃ | |
