Fiber Curing Oven Hortizonal type Control Temperature Heating Oven Fiber Optic Components
one set
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China Shenzhen
Brand Name: Hicorpwell
Certification: CE , IEC ,Reach,ISO9001-2015
Model Number: Fiber Optic Curing Oven
High Light:

fiber cable connectors

,

fiber quick connector

Payment & Shipping Terms
Packaging Details: Size: 400mmΧ320mmΧ160mm Neight: 12kg Total weight: 15kg
Supply Ability: 100 sets per week .
Specifications
Specification: 400mmΧ320mmΧ160mm
Voltage: 220-240V,
Connector Style Available: FC, SC, LC, MU, MTRJ, ST, MPO
Connector Heat Block: 30 Position
Power: 1100W
Temperature Adjustable Range: 0-200°C
Total Weight: 15kg
Frequency: 50/60Hz
Product Description



Fiber Curing Oven Hortizonal type Control Temperature Heating Oven Fiber Optic Components





Product Description of fiber cure oven:



• Temperature Control and "Power On” Indicator



• 30 Port Fiber Optic Epoxy Curing Oven



• 30 Port Epoxy Curing Oven provides cure for several types of epoxy and the oven block accomodates a variety of Optical Fiber connector



   types including ST, FC, SC, D4 and SMA. Block provides even heat distribution, minimizing  connector heat loss.



• Includes 24 Port Block for FC, ST, SC, SMA, D4 Connectors



• Available in AC 110V or AC 220V



• Easy to Use – A Favorite of Many Installers





KEY FEATURES:



1,Used to heat and weld Various fiber optical cable couplers, including FC, SC, ST, LC, MU and so on, especially suitable for



  processing MT and MPO fiber optical connectors;



2,it can simultaneously heat & weld 24 fiber optical couplers at the most; Even heating with low wear & tear of cable coupler;



3,Precise temperature control system can adjust the temperature within the 4,40-150 °C range,



   the temperature-control precision can reach ±1°C ;



5,Process equipment are replaceable, reducing the ancillary time;



6,; Process equipment with different number of wires & specifications and grill plates can be customized based on customer requirements.





Working voltage: AC220V
Operating frequency: 50-60HZ
Output: 800W
Temperature range: 0°C~300°C
Cores and Plates Can be customized
Temperature precision: ±2ºC
Temperature control type:  Electrical type
Produce Size: 400mmΧ320mmΧ160mm
Heating time: 99.99 hours adjustable
Cure various types of fiber optical connectors,  FC, SC, LC, MU, MTRJ, ST, MPO etc.
Total weight:  8KG
Operation :  simple and reliable



Main feature:



 •Special designed for curing epoxy of fiber optic connectors.



 • Suitable to different type of connectors, just change the heating block to save cost more







Fiber Curing Oven Hortizonal type  Control Temperature Heating Oven  Fiber Optic Components 0
