4 Port HD-SDI Fiber Transmitter With Ethenet & Bidi RS485
1 pcs
MOQ
negotiation
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HICORPWELL
Certification: IEC 60794-2-10/11
Model Number: 10/100/1000mbps Fiber Optic Converter
High Light:

4 Port HD-SDI Fiber Transmitter

,

hd-sdi to fiber converter

Payment & Shipping Terms
Packaging Details: Standard package for 1pair hd-sdi fiber transmitter : 1pcs SDI transmitter,SDI receiver, 2pcs DC5V2A power adaptors 1pcs user manual All with pearl cotton protection
Payment Terms: Western Union, L/C, T/T
Supply Ability: 1000pcs Per Week
Specifications
Function: 4ch Hdsdi+1 Bidi Rs485+10/100M Ethernet
Keyword: Sdi Transmitter
Distance: 0~80Km,20Km Default
Conversion Means: Media Conversion
Power Supply: DC 5V
Model Number: Fiber Media Converter
Transmission Speed: 10 / 100 / 1000Mbps
Wall Mount: Wall Mount
Product Description


4port hd-sdi fiber transmitter with ethenet&bidi rs485

The hd-sdi transmitter also named as hd-sdi to fiber converter,which supports 4ch hd sdi,

1 Bidi RS485 and 1CH half duplex/full duplex 10/100M ethernet transmission over 1 single mode fiber to 10~80Km.

It is a perfect and economic digital product for long distance with high resolution real-time video monitoring.

It’s widely used for broadcast on television, high-definition video conferencing, high-definition video surveillance and other fields.

Products Features

1, hd-sdi transmitter for 4 channel uncompressed hd-sdi video transmission over optic fiber

2, Compatible with SMPTE-292M HD-SDI and SMPTE-259M, SD-SDI standard signals, supporting 1485Mb / s , 270Mb / s rates

3, Support 1080I 60/50Hz, 720P 60/50/30/25Hz and many other video formats.

4, Support bidirectional RS-485 data protocols,up to 115.2Kb/s rates.

5, Support Full duplex and half duplex 10/100M ethernet

6, Automatic cable equalization to ensure signal integrity

7, Long transmission capability at least 10 km (6.2miles) , up to 80 km

8, ESD and surge protection circuit,which can effectively prevent static electricity and lightning damage

9, Provide light disappear alarm, remote power-down alarm, output signal status indication and input signal lock status indication

10, Ultra-broad temperature range (0~+55), adaptable to various environments;



Product Name:4port hd-sdi fiber transmitter with ethenet&bidi rs485

Video
Physical InterfaceBNC
Number of Channels4 Channels
Input/Output Impedance75Ω (unbalance)
Video Format

1080I 60Hz/50Hz,
720P 60Hz/50Hz/30Hz/25Hz

Video DirectionUnidirectional
Standard Video Input/Output Voltage0.8Vp-p
Video Voltage Range0.6~1.0Vp-p
Video Encoding bit width8bit or 10bit Auto
Return Loss≤-15dB 5MHz~1.5GHz,
Balanced Mode≤140meters of Belden 1694A at 1.485Gbps ≤400meters of Belden 1694A at270Gbps
Embedded Audio, Auxiliary Space, EDH DataTransparent
Optic
Fiber InterfaceFC(default),SC,LC selectable
Fiber TypeSinglemode(9/125μ single-mode optical fiber ,default),Multimode Selectable
Wavelength1310nm,1550nm
Distance 10~80KM(20Km default)
Number of Fiber 1
Data
Data ProtocolRS485
Data RateData Rate
ConnectorStandard Terminal Block(default),DB9/DB25 selectable
MTBF≥ 100000Hours


4 Port  HD-SDI Fiber Transmitter With Ethenet & Bidi RS485 04 Port  HD-SDI Fiber Transmitter With Ethenet & Bidi RS485 1
