Reinforced Tactical Cable Optical 2/4/6/8 Cores with Armored Glass Optical Fiber Cable

100M
MOQ
negotiation
Price
Reinforced Tactical Cable Optical 2/4/6/8 Cores with Armored Glass Optical Fiber Cable
Features Gallery Product Description Request A Quote
Features
Specifications
Fiber Type: G652D Or G657A1
Paintcoat Color: Black Or Blue Or Customized Jacket
Cable Purpose: Outdoor Usage
Length: 300M To 2000M Per Reel.
Application: Outdoor Communication
Connector Type: LC ,SC,FC,ST Optional
Fiber Type: SM Or MM
Common Name: 5G CPRI Cable
High Light:

fiber optic wire cable

,

fiber optic network cable

Basic Infomation
Place of Origin: China
Brand Name: HICORPWELL
Certification: IEC 60794-2-10/11
Model Number: Outdoor Armoured Glass Fiber Optic Cables
Payment & Shipping Terms
Packaging Details: 1000m/ Drum
Payment Terms: Western Union, L/C, T/T
Supply Ability: 5000km Per Week
Product Description

Reinforced Tactical Cable Optical 2/4/6/8 Cores with Armored Glass Optical Fiber Cable



Well-known as one of the leading outdoor Fo cable with rfp sm g657a1 manufacturers and suppliers



in China, our FO  calbes are equipped with advanced technology and many highly qualified staff.



Please be free to wholesale the customized products with us.





Description





FTTH outdoor cable, the optical fiber unit is positioned in the center.



Two parallel Fiber Reinforced steel wires(or FRP) are placed at the two sides.





Then the cable is completed with a black or color LSZH sheath.





Advantages





Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;



Two parallel steel wire/FRP strength members ensure good performance of crush resistance toprotect the fiber.



Simple structure, light weight and high practicability;



Novel flute design, easily strip and splice, simplify the installation and maintenance;



Low smoke, zero halogen and flame retardant sheath.



Used in 3/4/5G wireless base station horizontal and vertical cabling


1, Good mechanical and environmental characteristics;


2, Flame retardant characteristics meet the requirements of relevant standards;


3, The mechanical characteristics of jacket meet the requirements of relevant standards;


4, Soft, flexible, water blocked, UV resistant, easy to lay and splice, and with big capacity data transmission;


5, Meet various requirements of market and clients





Connector Specifications:

Item
Parameter
Connector Type
LC ,SC,FC,ST Optional
Fiber Type
SM-G657B3
Inertions loss
≤0.2dB
Return loss
≥50dB
Repeatability
≤0.1
Interchangeability
≤0.2dB
Durability
≤0.2dB
Fiber Length
1m,2m,3m,5m,10m etc for optional
Length and tolerance
+10cm
Operating Temperature
-45~+85℃
Storage Temperature
-45~+85℃





Cable Product perameter





Model Number GJXH,GJXFH
Type Coaxial
Number of Conductors 1--12
Certification UL ROHS ISO
OEM Welcome to OEM for FTTH outdoor Cable
Item FTTH outdoor Cable
Jacket Material LSZH
Laying method FTTH/FTTX/FTTA
Standards YD/T 1258.2-2003,ICEA-596,GR-409,IEC794,OFNR & OFNP
Application Outdoor wiring, building introduction
Operating Temperature -40 to 70 degree



Technical Parameters



Fiber count   Cable Tensile Strength Crush Resistance Bending Radius
Cable Diameter weight Long/short term Long/short term Static/Dynamic
mm kg/km N N/100mm mm
1 (2.0±0.2)*(3.0±0.2) 8 30/60 300/1000 15/30
2 (2.0±0.2)*(3.4±0.2) 8.5 30/60 300/1000 15/30
1 (2.0±0.2)*(3.8±0.2) 9 30/60 300/1000 15/30
4 (2.0±0.2)*(4.0±0.2) 10 30/60 300/1000 15/30





Reinforced Tactical Cable Optical 2/4/6/8 Cores with Armored Glass Optical Fiber Cable 0
