Vertical Magnetic Levitation Wind Turbine / Wind Power System 24V 300W 4000w
1set
MOQ
negotiation
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HICORPWELL
Certification: IEC & Intetek
Model Number: 300W 24V Maglev Wind Turbine
High Light:

Magnetic Levitation Wind Turbine

,

24V 300W Wind Power System

,

24V 4000w Wind Power System

Payment & Shipping Terms
Packaging Details: Plywood Package 0.27 CBM
Delivery Time: 15 working days
Payment Terms: Western Union, L/C, T/T
Supply Ability: 200pcs Per Month
Specifications
Name: 300W 24V Wind Generator Turbine
Blades Qty: 7 (3 Darrieusand 4 Savonius)
Color: Sliver And Customrized
Advantage: Magnetic Levitation Technology
Start Wind Speed: 1m/s
Dimension (Height/Diameter): Ø1324mm / 1457mm
Net Weight: 27 Kg
Volume Weight: 50KG
Cut-off Wind Speed: 15m/s
Survival Wind Speed: 60m/s
Product Description
Magnetic Levitation Wind Turbine Company Small Wind Power System Vertical Axis Wind Turbine With 24V on 300W 4000w


1,Description:





This 500W vertical axis maglev wind turbines undergoes a continuous improvement process,

which incorporates exterior design, utility design, electrical engineering, dynamic engineering, power mechanics, aviation air engineering, wind tunnel testing, lightening protection, computer simulation techniques and other multiple specialities.





2. Quick Detail:



  • Name : Maglev Wind Generator 300w-24V
  • Application :Generator in strong windy area for residential electricity
  • Sliver and customrized Color



3. Applications:



The unit provides a durable, reliable, and fully customized hybrid solution to Telecoms repeaters , Charging Station by Solar and wind and also very suitable for power supply to home.





4. Main Features:



  •  Magnetic levitation technology
  •  Independent of the direction of the wind
  •  Startup at low wind speed of 1m/s
  •
  •  Higher efficiency compared to traditional HAWT
  •  Works even in turbulence
  •  Visually pleasing appearance
  •  Design life: at least 20 years
  •
  •  Noise: Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db
  •  the Tower Foundation of Maglev Wind Generator 600w for the Antarctic area
  •  Turbine construction is resistant to gale 60m/s (132MPH)
  •  Robustness and adaptation to all possible environmental conditions thanks to material of aluminum alloy or stainless steel
