SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode
50 pcs
MOQ
negotiation
Price
SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HICORPWELL
Certification: ISO9001;2015
Model Number: SC with Shutter Type InGaAs Detector
High Light:

2mw Ingaas Detector

,

SC with Shutter Type InGaAs Detector

,

High Sensitivity InGaAs Detector

Payment & Shipping Terms
Packaging Details: ESD box
Payment Terms: Western Union, L/C, T/T
Supply Ability: 500pcs Per Week
Specifications
Type: SC With Shutter Type InGaAs Detector
High Responsivity: ≥0.85A/W 1310nm ≥o.90nm 1550nm
Forward Current: 30V
Laser Type: Fiber Laser
Payment: TT/PayPal
Max. Reverse Voltage: 15(PD)
Length Options: 0.1~1m Option
Fiber: SM 9/125
Power: 2mw
Package: ESD Box
Product Description

SC with Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode





The SC with Shutter Type InGaAs Detector  is most commonly used in CATV receivers,

power detection equipment and optical signal receivers for analog systems.

The 1100nm-1650nm small area InGaAs photodiode uses an InGaAs detector chip,

and features a low power consumption,small dark current, high sensitivity, great linearity, compact design and small volume.



1. Features:



Low Dark Current ,Low Return Loss

High Sensitivity

Coaxial Package ,Laser welding

Quick Pulse Response

High Reliability and Long Operation Life



2. Applications :



Analog Optical Receiver

Test Equipment

FTTH Network

CATV Forward/Return Path

EDFA Monitors

Optical transmission system



3. Absolute Maximum Ratings Tc=25°C:



Parameter Symbol Ratings Unit
Saturation power Ps 10.0 mW
Forward current If 10.0 mA
Reverser voltage Vr 30 V
Operating temperature Top -40~+85 °C
Storage temperature Tstg -40~+125 °C



























4.Optical and Electrical Characteristics Tc=25°C:





Parameter Symbol Min. Type Max. Unit Test condition
Operating Wavelength λ 1100 1310 1650 nm
Responsibility R 0.85 0.9   A/W Vr=5V=1310nm
0.9 0.95   A/W Vr=5V=1550nm
Dark Current Id   0.5 1.0 nA Vr=5V
Capacitance C   0.3 1.0 pF Vr=5V
Rise time/Fall time Tr/Tf     0.3 ns Vr=5V,10~90%
Bandwidth Bw 2.5     GHz Vr=5V







Hicorpwell is  a professional plug in InGaAs coaxial photodetector diode modules (analog optical active receptacle ROSA plug in)

manufacturer in China.

We also provide butterfly laser diodes, InGaAs coaxial pigtail laser detector diode, coaxial pigtail diode laser device

and more.



5.   PD Pin assignment :



                                           SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode 0





                                                                                                                                                                                                                                                                                                                                   SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode 1

SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode 2SC With Shutter Type InGaAs Detector Chip 1260-­1620nm Wavelength Small Area InGaAs Photodiode 3
