Well-known as one of the leading indoor drop cable with rfp sm g657a1 manufacturers and suppliers
in China, our FO drop calbes are equipped with advanced technology and many highly qualified staff.
Please be free to wholesale the customized products with us.
Description
FTTH indoor cable, the optical fiber unit is positioned in the center.
Two parallel Fiber Reinforced steel wires(or FRP) are placed at the two sides.
Advantages
Simple structure, light weight and high practicability;
Novel flute design, easily strip and splice, simplify the installation and maintenance;
Low smoke, zero halogen and flame retardant sheath.
Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;
Two parallel steel wire/FRP strength members ensure good performance of crush resistance toprotect the fiber.
Product perameter
Model Number | GJXH,GJXFH |
Type | Coaxial |
Number of Conductors | 1--12 |
Certification | UL ROHS ISO |
OEM | Welcome to OEM for FTTH Indoor Cable |
Item | FTTH Indoor Cable |
Jacket Material | LSZH |
Laying method | FTTH/FTTX/FTTA |
Standards | YD/T 1258.2-2003,ICEA-596,GR-409,IEC794,OFNR & OFNP |
Application | indoor wiring, building introduction |
Operating Temperature | -40 to 70 degree |
Technical Parameters
Fiber count | Cable | Tensile Strength | Crush Resistance | Bending Radius | |
Cable Diameter | weight | Long/short term | Long/short term | Static/Dynamic | |
mm | kg/km | N | N/100mm | mm | |
1 | (2.0±0.2)*(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
2 | (2.0±0.2)*(3.4±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
1 | (2.0±0.2)*(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
4 | (2.0±0.2)*(4.0±0.2) | 10 | 30/60 | 300/1000 | 15/30 |
